523 Tiny Tapeout - Mini CORDIC
523 : Tiny Tapeout - Mini CORDIC
- Author: Daniel Riquelme
- Description: A 4 iteration rotation mode CORDIC that computes sin and cos of a 6-bit angle
- GitHub repository
- Open in 3D viewer
- Open in Tiny Tapeout Explorer
- View in Wokwi
- Clock: 10000 Hz
How it works
Explain how your project works
How to test
Explain how to use your project
External hardware
List external hardware used in your project (e.g. PMOD, LED display, etc), if any
IO
| # | Input | Output | Bidirectional |
|---|---|---|---|
| 0 | angle bit 0, 0–63 = 0°–90° (1 LSB = 1.40625°) | 7-segment a–g bit 0 | |
| 1 | angle bit 1, 0–63 = 0°–90° (1 LSB = 1.40625°) | 7-segment a–g bit 1 | |
| 2 | angle bit 2, 0–63 = 0°–90° (1 LSB = 1.40625°) | 7-segment a–g bit 2 | |
| 3 | angle bit 3, 0–63 = 0°–90° (1 LSB = 1.40625°) | 7-segment a–g bit 3 | |
| 4 | angle bit 4, 0–63 = 0°–90° (1 LSB = 1.40625°) | 7-segment a–g bit 4 | |
| 5 | angle bit 5, after loading: 0 = cos, 1 = sin | 7-segment a–g bit 5 | |
| 6 | displayed nibble: 0 = low, 1 = high | 7-segment a–g bit 6 | |
| 7 | START: hold high to load the angle, release to compute | decimal point = DONE flag |
