587 Tiny Tapeout Test design
587 : Tiny Tapeout Test design
- Author: Aditya Bhardwaj
- Description: displaying a letter on 7 segment display using gates
- GitHub repository
- Open in 3D viewer
- View in Wokwi
- Clock: 0 Hz
How it works
Using AND, XOR, NAND gates are connected to inputs and outputs.
How to test
nput a b c and 1 or 0 11 00 01 10
11 1001 1010 0101 10201 101010
External hardware
List external hardware used in your project (e.g. PMOD, LED display, etc), if any none N/A
IO
| # | Input | Output | Bidirectional |
|---|---|---|---|
| 0 | nand1_A | nand1_OUT | |
| 1 | nand1_B | nand1_OUT | |
| 2 | not3_IN | not3_OUT | |
| 3 | not4_IN | not4_OUT | |
| 4 | |||
| 5 | |||
| 6 | or1_A___and1_A | and1_OUT | |
| 7 | or1_B____and1_B | or1 _OUT |
