585 Tiny Tapeout Template Copy Paul 1
585 : Tiny Tapeout Template Copy Paul 1
- Author: kermit-da-frog
- Description: random logic gates put together
- GitHub repository
- Open in 3D viewer
- View in Wokwi
- Clock: 10000 Hz
How it works
Explain how your project works wqjdpo
How to test
Explain how to use your project
External hardware
List external hardware used in your project (e.g. PMOD, LED display, etc), if any
IO
| # | Input | Output | Bidirectional |
|---|---|---|---|
| 0 | input a | a and b | |
| 1 | input b | c or d | |
| 2 | input c | (h or e) and (c or d) | |
| 3 | input d | f | |
| 4 | input e | b | |
| 5 | input f | h and (h or e) | |
| 6 | input g | f or g | |
| 7 | input h | h or e |
