847 alex_ha_192
847 : alex_ha_192
- Author: Alex Hegedus-Adkin
- Description: 8 x 8-bit -> 16-bit multiplier
- GitHub repository
- Open in 3D viewer
- Clock: 0 Hz
How it works
8-bit multiplier, goes to 16-bit internally, then outputs over the course of two cycles.
How to test
Right now we can feasibly test 65536 test cases, this will have to change if we increase the size of the thing.
External hardware
There isn't any for the time being. Maybe a display? That would need extra cycles though.
IO
| # | Input | Output | Bidirectional |
|---|---|---|---|
| 0 | in_1[0] | out[0] | in_2[0] |
| 1 | in_1[1] | out[1] | in_2[1] |
| 2 | in_1[2] | out[2] | in_2[2] |
| 3 | in_1[3] | out[3] | in_2[3] |
| 4 | in_1[4] | out[4] | in_2[4] |
| 5 | in_1[5] | out[5] | in_2[5] |
| 6 | in_1[6] | out[6] | in_2[6] |
| 7 | in_1[7] | out[7] | in_2[7] |
