229 IEEE Flappy Bird VGA Game
229 : IEEE Flappy Bird VGA Game
- Author: Escobar Mamani Alejandra Heidi
- Description: Flappy Bird hardware game with parallax scrolling for TinyVGA PMOD
- GitHub repository
- Open in 3D viewer
- Open in Tiny Tapeout Explorer
- Open in VGA Playground
- Clock: 25175000 Hz
How it works
This project implements a hardware-driven Flappy Bird game that outputs real-time 640x480 @ 60 Hz VGA graphics using procedural combinational logic without any frame buffers or external RAM.
How to test
Test the design by running tt_um_flappy_bird at 25.175 MHz on VGA Playground, executing the Cocotb testbench locally with make, or deploying on Tiny Tapeout hardware using a TinyVGA PMOD and push button.
External hardware
Tiny VGA Pmod driving a VGA monitor.
IO
| # | Input | Output | Bidirectional |
|---|---|---|---|
| 0 | Jump Button P1 | R1 | |
| 1 | Jump Button P2 | G1 | |
| 2 | B1 | ||
| 3 | VSync | ||
| 4 | R0 | ||
| 5 | G0 | ||
| 6 | B0 | ||
| 7 | HSync |
