Trial of Implementing the RO-based TRNG design
Just power up and get the data from the UART terminal
UART terminal, PC to run the randomness test, Oscilloscope to measure the RO output
# | Input | Output | Bidirectional |
---|---|---|---|
0 | RX_Serial | TX_Serial | |
1 | o_RO | ||
2 | o_RG | ||
3 | led | ||
4 | |||
5 | |||
6 | |||
7 |
