49 Multiply-Add
49 : Multiply-Add
- Author: yNiklas
- Description: Muliply-Add
- GitHub repository
- Open in 3D viewer
- Clock: 0 Hz
How it works
Input three 8-bit numbers A, B, C sequentially at consecutive positive clock edges. Upon the fourth positive clock edge, the result out=(A+B)*C is provided.
How to test
Insert 3 numbers, check result.
External hardware
None
IO
| # | Input | Output | Bidirectional |
|---|---|---|---|
| 0 | Input (A, B, or C) | (A+B)*C (after 4. clock posedge) | |
| 1 | Input (A, B, or C) | (A+B)*C (after 4. clock posedge) | |
| 2 | Input (A, B, or C) | (A+B)*C (after 4. clock posedge) | |
| 3 | Input (A, B, or C) | (A+B)*C (after 4. clock posedge) | |
| 4 | Input (A, B, or C) | (A+B)*C (after 4. clock posedge) | |
| 5 | Input (A, B, or C) | (A+B)*C (after 4. clock posedge) | |
| 6 | Input (A, B, or C) | (A+B)*C (after 4. clock posedge) | |
| 7 | Input (A, B, or C) | (A+B)*C (after 4. clock posedge) |
