174 Tiny Tapeout Test
174 : Tiny Tapeout Test
- Author: Kristoffer Matsumoto Mulbjerg
- Description: Segment Blink
- GitHub repository
- Open in 3D viewer
- View in Wokwi
- Clock: 1 Hz
How it works
1 Hz segment blink when 1st dip switch is ON.
How to test
Turn the 1st dip switch ON.
External hardware
Dip switch, 7 segment display
IO
| # | Input | Output | Bidirectional |
|---|---|---|---|
| 0 | a | a | |
| 1 | b | b | |
| 2 | c | c | |
| 3 | d | d | |
| 4 | e | e | |
| 5 | f | f | |
| 6 | g | g | |
| 7 | h | h |
