771 Snake
771 : Snake
- Author: Daniel Wagner
- Description: A snake travelling around the 7 segement display
- GitHub repository
- Open in 3D viewer
- View in Wokwi
- Clock: 1 Hz
How it works
Clk and Reset are connected to a row of flip flops which generate a time sequence. Each output of the flipflops indicate one explicit step. Each step then connects to the corresponding segments to create the moving snake.
How to test
Use the Step button to make the snake move one tile
External hardware
List external hardware used in your project (e.g. PMOD, LED display, etc), if any
IO
| # | Input | Output | Bidirectional |
|---|---|---|---|
| 0 | A | sevseg:A | |
| 1 | sevseg:B | ||
| 2 | sevseg:C | ||
| 3 | sevseg:D | ||
| 4 | sevseg:E | ||
| 5 | sevseg:F | ||
| 6 | sevseg:G | ||
| 7 | sevseg:DP |
