530 badstripes
530 : badstripes
- Author: malui
- Description: some bad attempt do put out something on the screen
- GitHub repository
- Open in 3D viewer
- Clock: 0 Hz
How it works
makes some stripes or other pattern on the vga channels. don't know this is a good idea.
How to test
Plug it in
External hardware
vga pmod
IO
| # | Input | Output | Bidirectional |
|---|---|---|---|
| 0 | x², x³, x⁴, x | ||
| 1 | x², x³, x⁴, x selection | ||
| 2 | x oscillation on/off | ||
| 3 | y oscillation on/off | ||
| 4 | centred_y truncation mode | ||
| 5 | x osc speed (0=fast, 1=slow) | ||
| 6 | y osc speed (0=fast, 1=slow) | ||
| 7 | free |
