555 TinyTapeout VGA Checker
555 : TinyTapeout VGA Checker
- Author: Adrian Trummer
- Description: Modified Checker module
- GitHub repository
- Open in 3D viewer
- Clock: 25175000 Hz
How it works
VGA Checker template was modified by reversing the direction & changing the default colors
How to test
Test the same way you would test the normal VGA Checker implementation (connect to VGA display and see if it displays the desired graphics)
External hardware
List external hardware used in your project (e.g. PMOD, LED display, etc), if any
IO
| # | Input | Output | Bidirectional |
|---|---|---|---|
| 0 | R1 | ||
| 1 | G1 | ||
| 2 | B1 | ||
| 3 | VSync | ||
| 4 | R0 | ||
| 5 | G0 | ||
| 6 | B0 | ||
| 7 | HSync |
