576 Yet Another Diffraction Grating Experiment
576 : Yet Another Diffraction Grating Experiment
- Author: htfab
- Description: A remix of Uri's Colorful Stripes
- GitHub repository
- Open in 3D viewer
- Clock: 0 Hz
How it works
Should hopefully generate a colorful pattern when viewed under the microscope.
How to test
View under the microscope or smartphone camera.
External hardware
Microscope.
IO
| # | Input | Output | Bidirectional |
|---|---|---|---|
| 0 | None | ||
| 1 | |||
| 2 | |||
| 3 | |||
| 4 | |||
| 5 | |||
| 6 | |||
| 7 |
